Industrial Electric Motor Horizontal Mixed Flow Pump 6500m3/h Anti Chemical

Name: Industrial Electric Motor Horizontal Mixed Flow Pump 6500m3h Anti Chemical
Brand: Chengdu Yongyi
Price: 500 USD

China Industrial Electric Motor Horizontal Mixed Flow Pump 6500m3/h Anti Chemical wholesale

Brand Name : Chengdu Yongyi

Model Number : YYTL

Certification : ISO9001

Place of Origin : Sichuan, China

MOQ : 1 set

Price : USD 500-5000/set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal

Supply Ability : 300 Sets/Month

Delivery Time : 25 working days after receiveing advance payment

Packaging Details : free fumigation export wooden box packaging

Theory : Mix Flow Pump

Flow : 200-6500m3/h

Head : 8-25m

Impeller : Closed/ Semi Open

Brand : Chengdu Yongyi

Pressure : 1.6MPa

Flange : Customized

Condition : New

Name : Flue Gas Desulphurization Pump

Contact Now

Industrial Electric Motor Chemical Horizontal Volute Mixed Flow Industrial Pump 6500m3/h Anti Chemical Pump

Features

1. Advanced computer simulation analysis technology, the pump has excellent performance and high reliability and stability.

2. YYTL-series pump has the features of simple structure, convenient maintenance and reliable operation.

3. Meets the wear-resistance and corrosion resistance requirements of slurry for conveying different media conditions.

4. Rotor component axially movable

Performance Data

Discharge Size	Inlet Size	Capacity	Head	Maximal Efficiency	RPM
200mm~800mm	250mm~900mm	200-6500 m³/h	8-25 m	90.2%	1450 r/min

Technical Parameter

Model	flow (m³/h)	Head (m)	Speed (r/min)	Maximum efficiency (%)	NPSH(NPSHr) m	Allowable maximum motor power(KW)	Net weight (kg)
350YYTL-24	1280	25.2	740	75	6.5	200	3200
	1600	24		80
	1920	22.3		81
350YYTL-10	640	11.2	490	72	3.4	55	3200
	960	10.2		78
	1060	9.1		79
400YYTL-24	1760	25.5	740	80	6.8	280	3500
	2200	24		82
	2640	22		83
400YYTL-10	1160	11.3	490	78	3.2	75	3500
	1450	10.5		80
	1740	9.4		81
500YYTL-24	2800	25.8	590	82	7.1	450	4500
	3500	25		85
	4200	21.6		86
500YYTL-16	2320	18.2	490	82	3.8	75	4500
	2900	16.5		85
	3480	14.8		86
600YYTL-24	4500	25.5	590	83	8.0	710	6000
	5500	24		87
	6500	22		88
600YYTL-16	3737	17.6	490	83	5.5	400	6000
	4568	16.6		87
	5400	15		88
700YYTL-24	6400	25.5	490	84	8.0	1000	8000
	8000	24		88.5
	9600	21.5		89.5
700YYTL-18	5550	19.2	425	84	6.1	630	8000
	6940	18		88.5
	8327	16.2		89.5
800YYTL-24	8250	27	490	87.5	9.6	1250	8800
	10500	24		89.5
	12000	21.3		87.5
800YYTL-18	7156	20.3	425	87.5	7.2	800	8800
	9100	18.1		89.5
	10400	16		87.5
900YYTL-24	12000	26	370	86	8.3	1800	11400
	15000	24		90
	18000	21.5		90.2
900YYTL-19	10700	20.7	330	86	6.6	1250	11400
	13380	19.1		90
	16050	17.1		90.2

Transfer Method

Direct connection:	The pump and motor are directly connected to the motor through a long diaphragm flexible coupling.
Belt drive:	Change the speed to adjust the pump performance through the V-belt drive.
Reducer:	Reduce speed through reducer, suitable for high power pump

Product Picture

Industrial Electric Motor Horizontal Mixed Flow Pump 6500m3/h Anti Chemical

Industrial Electric Motor Horizontal Mixed Flow Pump 6500m3/h Anti Chemical

Why choose us:

1.Professional electric chemical pump set manufacturer

2.Decade years of manufacturing and exporting experience

3.Adopt International quality standards, to guanantee the quality
